ACTIVE SCANNING WINDOW
| 0,8" x 0,7"- Single flat finger
|
IMAGE RESOLUTION & QUALITY
| FBI/PIV certified at 500 dpi, 8-bit
|
INTERFACE
| 2.0 (Power and Data)
|
QUALITY AND FORMATS
| ANSI/NIST-ITL 1-2007/2011, ISO/IEC FCD 19794-4, ANSI/NIST-ITL 1-2000, ANSI/NIST-ITL 1-2000 Interpol Implementation
|
SUPPORTED OPERATING SYSTEMS
| Microsoft Windows up to Win 10 in 32-bit and 64-bit configuration, Linux Ubuntu and Fedora distributions in 32-bit and 64-bit configuration, Android
|
FAKE FINGER DETECTION
| HW based to guarantee highest efficiency
|
TEMPERATURE
| Storage: from -20°C to +60°C - Operating: from 0°C to +50°C
|
HUMIDITY
| From 10 to 90% non-condensing
|
WEIGHT
| 175 gr.
|
DIMENSIONS
| 50 x 68 x 43 mm
|
CERTIFICATIONS
| CE, FCC, RoHS
|
IP RATING
| IP54
|
OPTIONS
| DactyMatch SW
|
STANDARDS
| ISO 7816 & EMV 2000 level 1
|
PROTOCOLS
| T=0, T=1, 2-wire: SLE 4432/42 (S=10), 3-wire: SLE4418/28(S=9), IC (S=8)
|
SMARTCARD DETECTION
| Movement detection with auto power-off. Automatic detection of smart card type. Short circuit and thermal protection
|
CARD SIZE
| ID-1 (full-size)
|
INTERFACE SPEED
| 420 kbps (when supported by card)
|
CLOCK FREQUENCY
| Fixed at 4.8Mhz
|
SUPPORTED CARD TYPES
| 5v, 3V and 1.8V Smart Cards, ISO 7816 Class A,B and C
|
SUPPORTED CARD TYPES
| 5v, 3V and 1.8V Smart Cards, ISO 7816 Class A,B and C
|
POWER TO SMART CARD
| 60mA
|
STATUS INDICATOR
| color LED
|
COMPLIANCE CERTIFICATION
| Microsoft WHQL EMV 2000 LEVEL 1
|
